UC200: 192.168.12.12
Analog Gateway (FXO): 192.168.12.13
We are adding an extension on the switchboard.
Extension Trunk must be set to True in the Advanced tab.
We define the outbound call rule. This rule will work for numbers starting with 8.
Incoming calls will work without adding a route because GW is added internally.
Gateway Settings
GW is registered to the switchboard by entering the internal number, password and switchboard information.
The number we want to appear on the gateway is defined.
Port definition/selection is made. The port register is selected as the gateway.
IP-TEL and TEL-IP settings are made as follows.
Since the Authentication Method in the Port Group settings is registered with the UC200 as the gateway, there is no need to create TEL-IP routes.
